D28 Plasma Nitrided Welding Tables-Plasma Nitrided 3D Welding Tables-3D Precision Welding Tables | SANWZB - Welding Tables-Dongguan Sanwei Flexible Auto-Equipment Co., Ltd


D28 Plasma Nitrided Welding Tables
Plasma Nitrided 3D Welding Tables

These 3D welding tables are built from hardened steel to begin with, and then go through an additional nitride process to harden the top work surface. The optional plasma-nitride finish provides dramatically increased resistance to weld splatter, corrosion and scratching as well as offering the ability to use the table for stainless steel applications.

The tables feature five fixturing surfaces constructed from 1 inch (25mm) thick plate with additional reinforcement underneath the work surface. Fixture mounting holes are CNC machined to 28mm diameter, feature radiused edges, and are laid out in a diagonal grid for superior clamping flexibility.
